5G-NTN Modem IP for Satellite
User Terminals

Ceva-PentaG-NTN

PentaG-NTN is a 5G Non Terrestrial Network (NTN) modem IP subsystem optimized for satellite user terminals operating in LEO and MEO constellations.



Built on Ceva’s third-generation PentaG platform, it addresses the unique technical challenges of non-terrestrial networks while enabling rapid integration into satellite SoCs.



Delivered as a fully validated modem subsystem, PentaG-NTN enables satellite-native innovators and semiconductor companies to deploy standards-based 5G-NTN connectivity without the cost and complexity of developing a cellular baseband modem from the ground up.



The Solution

PentaG NTN is a fully validated 5G NTN Modem IP, delivered as an integrated, plug‑and‑play baseband modem subsystem.

Ceva’s PentaG‑NTN Simulation: The Future of Satellite Communication

It accelerates product development, reduces engineering effort, and streamlines SoC integration, all while ensuring robust performance and minimizing development risk.



Benefits



  • Reduces integration complexity for satellite-focused design teams
  • Accelerates time-to-silicon for 5G-NTN terminal SoCs
  • Minimizes modem development risk with validated subsystem architecture
  • Enables differentiation through programmable DSP and flexible software interfaces
  • Provides a scalable foundation aligned with 3GPP Release 18 and future enhancements





Key Features



Optimized for LEO and MEO Satellite Dynamics

  • Doppler compensation and frequency-offset mitigation
  • Latency-aware L1 processing tuned for extended propagation delays
  • Robust synchronization for rapidly changing channel conditions



Standards-Based 5G-NTN Support

  • 3GPP Release 18 compliant
  • Upgrade path toward Release 19
  • Support FR1 and FR2/ mmWave, tuned to Ka/Ku bands
  • Scalable throughput from 10 Mbps to 2 Gbps
  • Up to 256-QAM modulation



Flexible and Differentiable Architecture

  • Hardware-accelerated signal processing for performance efficiency
  • Programmable DSP resources for proprietary algorithm integration
  • Support for custom waveform extensions alongside 3GPP standards
